ZALMAN MEGAMAX 500W V2 80 PLUS STANDARD : ZM500-TXII
คุณสมบัติ POWER SUPPLY (80+ WHITE) 500W ZALMAN MEGAMAX ZM500-TXII
| Brand | ZALMAN |
| Model | MegaMax ZM500-TXII |
| Type | Intel ATX 12V Ver2.31 |
| Power Capacity | 500W |
| Input Voltage | 200-240 VAC |
| Input Current | 4A |
| Input Frequency Range | 50-60Hz |
| Operating Temperature | 10-45 ? |
| Fan Size | 120mm |
| Efficiency | Max 86% @ 220VAC, Typical Load |
| MTBF | 100,000Hours |
| Safety Regulation | KC, CE, CB, RoHS, EAC |
| Protection | OPP/OVP/UVP/SCP |
| Certification | 80 PLUS WHITE |
| Modular | Non Modular |
| ATX Main Connector | (24 Pin) x 1 Connector |
| CPU Power Connector | (4 Pin) x 1 Connector (8 Pin) x 1 Connector |
| PCIe Power Connector | (6+2 Pin) x 2 Connector |
| SATA Power Connector | 6 Connector |
| Peripheral Power Connector | 3 Connector |
| Floppy Power Connector | 1 Connector |
| RGB Power Connector | None |
| Dimension | (W x D x H) : 15.00 x 14.00 x 8.60 cm |
| Net Weight | 1.63 KG |
| Package Dimension | (W x D x H) : 18.50 x 28.50 x 10.00 cm |
| Gross Weight | 2.00 KG |
| Volume | 5,272.50 cm3 |
