THERMALTAKE CASE DIVIDER 500 TG AIR SNOW

THERMALTAKE CASE DIVIDER 500 TG AIR SNOW CA-1T4-00M6WN-02

P/NCA-1T4-00M6WN-02SERIESDividerMODELDivider 500 TG Air SnowCASE TYPEMid TowerDIMENSION (H X W X D)530 x 230 x 466 mm
(20.9 x 9.1 x 18.3 inch)NET WEIGHT10.29 kg / 22.69 lbs.SIDE PANEL3mm Tempered Glass x 2COLORWhiteMATERIALSPCCCOOLING SYSTEMFront(intake):
120 x 120 x 25 mm fan (1200rpm, 22 dBA) x 1
Rear(exhaust):
120 x 120 x 25 mm fan (1200rpm, 22 dBA) x 1DRIVE BAYS
-ACCESSIBLE
-HIDDEN2 x 3.5”, 5 x 2.5”
or 7 x 2.5”
EXPANSION SLOTS7 (Rotatable Patented Design)MOTHERBOARDS6.7″ x 6.7″ (Mini ITX), 9.6″ x 9.6″ (Micro ATX), 12″ x 9.6″ (ATX)I/O PORTUSB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1PSUStandard PS2 PSU (optional)FAN SUPPORTFront:
3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Right (M/B Side):
2 x 120mm, 1 x 120mm
Rear:
1 x 120mm
RADIATOR SUPPORTFront:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Top:
1 x 280mm, 1 x 140mm
1 x 240mm, 1 x 120mm
Right (M/B Side):
1 x 240mm (vertical-installed GPU recommended),
1 x 120mm
Rear:
1 x 120mm
CLEARANCECPU cooler max height:
155mm (with one TG and one steel side panel)
170mm (with two TG)
VGA max length:
360mm (with radiator)
390mm (without radiator)
PSU max length:
180mm (with HDD Cage)
220mm (without HDD Cage)
