MAINBOARD (เมนบอร์ด) MSI PRO B760M-E DDR4 (SOCKET LGA 1700) (MICRO-ATX)
คุณสมบัติ MAINBOARD (1700) MSI PRO B760M-E DDR4
| Brand | MSI |
| Model | MSI PRO B760M-E DDR4 |
| CPU Support | Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors LGA 1700 |
| Socket | 1700 |
| Chipset | INTEL B760 |
| Memory Support | 2x DDR4, Maximum Memory Capacity 64GB Memory Support 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) Max. overclocking frequency: • 1DPC 1R Max speed up to 4800+ MHz • 1DPC 2R Max speed up to 4600+ MHzSupports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) |
| Memory Type | DDR4 |
| Memory Bus | 2133/ 2666/ 2933/ 3200 |
| Maximum Memory Bus | 4800 |
| Memory Slot | 2 |
| Graphics | 1x HDMI™ 1x VGA Support HDMI™ 1.4 with HDR, maximum resolution of 4K 30Hz* Support VGA, maximum resolution of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Multi Graphic Support | N/A |
| Audio | Realtek® ALC897 Codec 7.1-Channel High Definition Audio |
| Expansion Slots | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 PCIe 4.0 supports up to (From CPU) PCI_E2 PCIe 3.0 supports up to (From Chipset) |
| Maximum PCIe Version | PCIe 4.0 |
| Storage | 1x M.2 slot M.2_1 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G port * SATA5 will be unavailable when installing M.2 SATA SSD in the M2_2 slot. |
| M.2 Storage Type Support | PCIe 4.0 |
| USB |
4x USB 2.0 (Rear)
|
| Internal I/O Connectors | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 2x USB 2.0 1x USB 3.2 Gen1 Type A |
| Back Panel Connectors | HDMI™ VGA Keyboard / Mouse USB 3.2 Gen 1 5Gbps (Type-A) LAN port Audio Connectors USB 2.0 USB 2.0 |
| LAN | Realtek® RTL8111H Gigabit LAN |
| Wireless Data Network | N/A |
| Form Factor | mATX 200mmx236.16mm |
| H/W Monitoring | N/A |
| BIOS | N/A |
| Special Features | N/A |
| Software Features | N/4 |
| Operating System Support | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| Package Contents | N/A |
| Package Dimension | (W x D x H) : 26.00 x 26.00 x 5.50 cm |
| Gross Weight | 0.70 KG |
| Volume | 3,718.00 cm3 |
